◆好產品特別 Product features
此機型為兩用型模具及滾筒噴砂機,產品類小工件產品可以批量生產用滾筒來生產提高了生產產量,重型工件可以使用轉臺降低工人的勞動強度,大大的滿足了客戶的需求。
The machine is available mould and roller sandblasting machine, Class products can batch production small workpiece with roller to improve manufacturing output, Heavy workpiece can use turntable to reduce the labor intensity, Fully meet the customer's requirements.
◆主要的水平參數指標 Main technical parameters
服務器規格 Model |
STR-1010滾筒模具兩用噴砂機 |
辦公艙寬度 Internal size(mm) |
1000×1000×790 |
該機尺碼 Complete machine size(mm) |
1000×1540×1830 |
24v電源 Power |
220V 50Hz |
機子燈光燈 Machine floodlight |
220V 13W能效燈 |
分離法器直流無刷電機 Separator motor |
220V 50Hz 550W |
拆分器排風量 Separator air volume |
8.5m3/min |
再壓縮熱空氣源 Compressed air source |
2-8bar(kg/cm2) |
轉臺直勁 Turntable diameter(mm) |
500 |
轉臺承受力 Turntable bearing |
150kg |
滾簡承重力度 Roller bearing |
10-30Kg |
電腦凈含量 Machine net weight |
380 kg |
