STR-環保風力循環回收式噴砂房效果圖

STR-Environmental protection wind cycle recovery sandblast room designsketch

◆噴砂（丸）房的構成系統的

Composition of the sandblasting (shot) room system

1、本職工作室項目  Studio

2、噴砂操作系統  Sandblasting  system

3、爐料回收公司系統化  Abrasive recycle system

4、除塵處理系統性  Dust removal system

5、工件表面氣流輸送系統化  Workpiece conveying system

6、有效過程控制系統軟件  Control system

7、照明燈體系  Lighting system

 ◆符合時間范圍 Applicable scope

大中型鑄件鍛件、悍接鋼構的、箱式變壓器水箱、工程項目物理、摩托此車、鍋爐風機生產、所有物理、船舶制造修造等噴砂防銹。

Large castings and forgings welding steel structure, transformer oil tank, engineering machinery, locomotives, boiler manufacturing, chemical machinery, ship building blast cleaned, etc.

 ◆商品作用 Product features

噴砂房是我公司在蜂窩地板技術的基礎上，自行開發、設計的環保型蜂窩式噴砂（丸）房，可按客戶的產品特性、噴砂要求等設計制作。蜂窩地板噴砂房是利用風機的風力為動力，將磨料通過回料管道吸送到旋風分離器中進行分離，最后進入噴砂系統循環利用。

Sandblasting room  is our company in introducing foreign advanced cell technology based on the floor, , the development, the design of the environmental protection cellular gush arenaceous (shot) room by ourselves, according to customers' product characteristics, sandblasting design requirements, etc. Cellular floor gush arenaceous room is the wind power by fan for abrasive materials, will back through the pipe to cyclone separator suction of separation and finally into gush arenaceous system recycling.

具備這特點：

1、省去了常規噴砂房砂料輸送煤循環系統的螺旋輸送機，斗式提升機以及地下工程，不需建造地坑，節約了地基施工費用，大大節約了工程成本；

2、耐磨材料回收處理率高，用于清換耐磨材料；

3、主耍電力工程部件均按照國外進口商品，兼具性能指標安穩，衛生耐用，采用保修期長，維系方便；

4、噴砂房室體內有高清晰的能見度，室體自然補風，節約能源消耗；

5、機器按照雙極排塵器，1、級按照漩風剝離 器，第五級用濾清器式排塵器程序，其總排塵器的效率高達99.99%以上內容；

6、在噴砂房正面房頂上部，配有“聲光報警系統”，在噴砂房內，配有急停呼叫按鈕；

7、各軟件操作系統軟件電機把控好操作系統軟件采用了互鎖把控好，當中僅一軟件操作系統軟件造成常見故障時，相關聯軟件操作系統軟件均關閉辦公，噴槍關閉噴射式；

8、房體進行房子裝飾定制，外觀設計簡易、美化、規定，消除噪音效果非常的好好，且配置快速。

Advantages

1. Omitted conventional Sandblasting room sand conveying coal circulation system, screw conveyor a pattern lift machine and underground project, no need to build the pit and save foundation pit construction cost, greatly reduce the project cost;

2. high  abrasive recycle efficiency, easy to change abrasive;

3. The main electrical components are imported products, have the stable performance, safety and reliability, long life, easy maintenance;

4. Sandblasting room inside has high-resolution visibility, Chambers fill the wind, save energy natural consumption;

5. This machine use double levels of dust removing, the first level is the cyclone separator, the second type is filter dust removal system. Its total removal efficiency may reach above 99.99%;

6. In sandblasting room roof, equipped with a "positive upper sound-light alarm system", in the room, sandblasting with abrupt stop call button;

7. The electric control system uses interlock control, while one system malfunction, related system are to stop working, stop spraying gun;

8. Building decoration design room body appearance, simple , beautiful, standard, good noise reduction result  and convenient installation.
