噴砂（丸）房系新產品

飛機按段涂裝設備房-海船特涂儀器

Ship section coating room-special ship coating equipment

1、套強制力要求性噴涂工程施工安全了；必要性是保護性海底工作環境；一回、多次進行處理Sa2.5級；一個能保證表層計劃使用的壽命短15年道路施工枝術。

2、（表面園角）2mm；表層毀損不低于2%或25m2,噴砂清理Sa2.5級。

3、（有粗糙度）30-75um；外表面溫度比露點高3℃；干膜尺寸320um。

4、（粒子規模）3、4、5灰層布局1級；眼睛內見更小積塵清除。

5、（氯化鈉）50mg/m2；500總噸船用海艙；150m長散貨船雙舷側。

6、涂漆水平產品規格書6維度：企業產產品品牌、表層素材、作業做法、膜厚比率、前清理、環境。

7、70%Sa2級（試驗裝置不和睦格底漆）；符合標準底漆掃砂或高壓變壓器水清潔。

8、（相對來說含水率）超過85%。

9、90/10方式：90%達成規范標準值，10%達到規范標準值的90%。

1.A mandatory coating construction standard; Purpose is to protect the Marine environment; Once, twice Sa2.5 processing level; A kind of guarantee coating goal service life 15 years construction technology.

2.(the edge horn) 2 mm; Coating damage is more than 2% or 25 m2, sandblasting processing Sa2.5 level.

3.(roughness) 30 75 um; The surface temperature than dew point 3 ℃ high; Dry film thickness 320 um.

4.(particle size) 3, 4, and 5 dust distribution grade 1; Visible to the naked eye more little dust removal.

5.(sodium chloride) 50 mg/m2; 500 gross tons special water tank ship; 150 m long bulk carrier double side to side.

6.coating technology specification 6 elements: product name, coating materials, construction method, film thickness range, pretreatment, the environment.

7.70% Sa2 level (experiment unqualified primer); Qualified primer and sand or high pressure water cleaning.

8.(relative humidity) less than 85%.

9.90/10 rule: 90% to 10% of the value standard of 90%.

隨著規程的標準，人們的產品可能性有一些：

1、我們公司行人認為僅有涂料房不務必能足夠PSPC實驗室管理標準，就也沒有噴涂房更無法實現實驗室管理標準；因就也沒有噴涂房的各位會作用建筑，有噴涂房的各位會作用完整。

2、15年的使用生存期的要求，會對一些企業有效仿的作用。

3、周圍環境我們都不錯要做到無危害。

4、Sa2.5級代表著高效性噴砂和環保再生資源回收軟件系統的操作和緩和。

5、粗糟度調節暗示著磨料磨具分離裝備的規定要求提供了（存儲細科粒，去掉塵土）。

6、工作溫度、氣溫、板材厚度測量檢測設備器食用率極大程度上延長。

7、海水鹽度、擦洗度、灰層檢查過多選購。

8、表層除塵系統（電動式、手動、防震）非常多的便用。

9、表面處理房照明系統安全設施將會必須優化，選用燈、設計擺置、按照裝修工程。

10、為絕對自然環境禁止必要條件：適當合理的煙氣凈化控制系統的軟件、低能耗的電加熱控制系統的軟件、靠普的除濕氣控制系統的軟件當上噴涂裝修工程要機械設備。

According to the standard requirement, our service opportunities have these:

1.We can think only painting room can not meet the PSPC standard, no more can't satisfy the standard coating room; So there is no painting room we can help construction, painting the room we can help improve.

2.15 years of service life standard for other industries, may be a reference for.

3. we can do no pollution environment.

4.Sa2.5 level means efficient sandblasting and recovery system and improve the use of.

5.Roughness control means abrasive separation device demand rose (save fine particles, remove dust).

6.Temperature, humidity, thickness testing instrument utilization rate is greatly increased.

7.And salinity, cleanness and dust detection in large quantities.

8.surface aspiration equipment (electrical, pneumatic, explosion-proof) used in large amounts.

9.Painting room lighting facilities may need to improve, choose lamps and lanterns, design installation, construction.

10.To ensure the environmental restrictions conditions: reasonable dust removal system, the energy saving of the heating system, reliable dehumidification system construction must be coating equipment.

對運輸船只修造行業中IMO耐磨涂層效能標準的(PSPC)的實施，斯特爾機械提供船舶噴砂涂裝設備系統整體解決方案及技術支持，為船舶修造行業設計制造完善的船舶分段噴砂房噴漆房，鋼板拋丸預處理線，舾裝件、艙口蓋等船體部件二次分段涂裝房，壓載艙特涂設備，連續高效噴砂設備及回砂系統設備，精準的砂塵分離裝置，環保節能型除塵設備，大中型真空吸砂設備，組合式除濕機，高效暖風機，移動防爆風機，電動/氣動平衡/防暴型集塵設施，直流高壓水難以清理設施，氣溫、含水率、機的薄厚探測實驗儀器，含鹽量、衛生度、臟污用探測設施。

Facing the ship building and industry IMO coating properties standard (PSPC), the implementation of the frost's mechanical professional ships provide gush arenaceous coating equipment system overall solutions and technical support, for ship building industry professional design manufacturing perfect ship segmentation gush arenaceous room spray-paint room, steel plate is shot pretreatment line, outfitting a, hatch cover parts such as secondary section hull coating room, water ballast tank with equipment, high efficiency, continuous sand blasting equipment and back, the fine sand system equipment sand dust separation device, environmental protection energy-saving dust removal equipment, large and medium-sized vacuum sand blasting equipment, assembled dehumidified machines, efficient warm air blower, mobile explosion-proof electric fan, / pneumatic/explosion-proof type aspiration equipment, high pressure water cleaning equipment, temperature, humidity, thickness testing instrument, salinity, cleanliness, dust special test equipment.
